MTH Bronze Fitted Regenerative Turbine Pump
5 HP 208-230/460V 3 PH, ODP# T51P-BF T21

MTH Bronze Fitted Regenerative Turbine Pump 5 HP 208-230/460V 3 PH, ODP# T51P-BF T21 (XM8)
Item# MTH-PMP-8CT510PBFSCSXSAXX-C059ED
List: $2,417.00
Value Priced $1,933.60
Availability: ships in 1-2 weeks

Description

MTH Bronze Fitted T51P-BF T21 5 HP 208-230/460V, 3 Phase, ODP motor, Regenerative Turbine Pump. Mechanically sealed regenerative turbines for low flow high pressure applications. Serving a wide variety of markets and industries including boiler feed, condensate return, chillers / temperature controllers, refrigeration, petroleum, as well as the chemical industry and many other process applications. All units are tested to specifications before leaving the factory. Low NPSH Requirements.



Specifications

Applications: Flooded Suction, Boiler Feed, Chemical, Condensation, Irrigation, Coolant and High Pressure. Construction: Body: Bronze Fitted, Viton A elastomers, viton/carbon seals and viton/ceramic seats and stainless steel shaft. End Suction/Top Discharge: T51 Series pumps are compact to allow installation in small areas. The discharge can be rotated to 90 degrees, 180 degrees and 270 degrees positions to facilitate the most convenient installation. Temperature: to 300 F Connections: 1-1/4" FNPT inlet and 1" FNPT outlet. Motor: All D3 motors feature a 304 stainless steel shaft and CE mark approval. T51 pumps can accept most commonly available motors through the use of close or flexible coupling. For wider fluid compatibility, T51 units feature a protective motor shaft sleeve. ODP Motor allows operation at two pole or four pole speeds 3450 RPM. Electrical: 5 HP, 3450 RPM, 208-230/460 Volt, 3 Phase, 60 Hz. Weight: 70 lbs.




MTH-PMP-T51-Series-bulletin.pdf
MTH-PMP-T51-Series-Manual.pdf
