Myers Mini-Max 1/2 HP, 230 volts 1 phase, 60 HZ, 9.8 amps, 3" deep well submersible pumps . Centrifugal multi-stage, 3-wire, with electric motor with thermal overload and lightning protection. & control box. Lead-free, all stainless steel exterior. Long-life corrosion resistant stacked impeller design. Built-in poppet type check valve. Screened inlet with 1" FNPT outlet.
IMPORTANT INFORMATION FOR INSTALLERS OF THIS EQUIPMENT!
The equipment is intended for installation by qualified, licensed contractors.
This is NOT a do-it yourself product. |
In stock item .....Usually ships next business day.
Specifications
- Construction: Lead-free, all stainless steel exterior. Long-life corrosion resistant stacked impeller design.
- Check Valve: Built-in poppet type
- Inlet: Screened inlet
- Outlet: 1" FNPT.
- Electrical: 230 volts, 1 phase, 60 Hz, 1/2 HP, 9.8 amps. submersible electric motor with thermal overload and lightning protection.
- Lead wire length (Pigtail): 30"
- Carton Dimensions: 5" high, 48 long, 5" wide.
- Weight: 40 lbs
- Required control box (included in price): Nema 4 control box rated and sized to fit inside well casing or replacing a 2-wire system.
- Suggested accessories: 12/4 submersible wire (order separately)
Capacity At Depth To Water In Feet With 0 Tank Pressure
| Depth to Water |
50' |
90' |
120' |
170' |
200' |
245' |
285' |
| GPM |
16 |
14 |
12 |
8 |
6 |
4 |
0 |
|
