MTH Bronze Fitted T41D-BF T21, 1/2 HP 208-230/460V, 3 Phase, ODP motor, Regenerative Turbine Pump. Close-coupled regenerative turbine pumps represent the most economical, high performance alternative for low flow (1/2 to 22 GPM) clean fluid applications involving moderate to high pressures (heads to 600 feet).
By combining the latest concepts in hydraulic turbine pump design with precision computer controlled manufacturing, the T41 Series pumps deliver high efficiency operation even at low NPSH. Costs are controlled by efficient manufacturing processes and highly optimized pump designs. Maintenance costs are kept to a minimum by combining an easily serviceable design with the use of high quality components to provide long life.
Applications: Flooded Suction,
Boiler Feed, Chemical, Condensation, Irrigation, Coolant and High Pressure.
Construction: Body: Bronze Fitted, Buna elastomers, high temperature carbon seals and ceramic seats for best hot water service.
End Suction/Top Discharge: T41 Series pumps are compact to allow installation in small areas. The discharge can be rotated to 90 degrees, 180 degrees and 270 degrees positions to facilitate the most convenient installation.
Temperature: to 300 F
Connections: 1" FNPT inlet and outlet.
Motor: All D3 motors feature a 304 stainless steel shaft and CE mark approval. T41 pumps can accept most commonly available motors through the use of close or flexible coupling. For wider fluid compatibility, T41 units feature a protective motor shaft sleeve. ODP Motor allows operation at two pole or four pole speeds 3450 RPM.
Electrical: 1/2 HP, 3450 RPM, 208-230/460 Volt, 3 Phase, 60 Hz. Weight: 35 lbs.
