Pearl by Calpeda Water Boosting Pump System 3/4 HP 115/1/60, 20 GPM at 40 PSI, FBSMS07-25G30PA. Ideal for average to large two story homes or long runs of plumbing. Six water outlets can be operated at the same time without substantially reducing performance.
Replaces Davey HS18-30HTI
The Flux control starts the pump as soon as you switch on the tap and continues running until water is not required. The controller continuously monitors the flow of water and will switch it off to avoid damage if the supply becomes inadequate. The systems are compact, quiet and easy to install.
Applications Domestic water supply, pressure boosting from city. Type of pump: Centrifugal single stage
Pump construction: 304 Stainless steel and corrosion-resistant materials.
Maximum operating pressure: Do not exceed 75 PSI
Water Pump Protection: Outdoor Use
FLUX protection: Water Resistant
Tank size: Does not require an additional pressure tank under normal operating conditions. Suction lift: None Maximum inlet pressure: 50 PSI (Must install a pressure reducing valve on the suction side of the pump if the inlet pressure is more than 50 PSI)
Electrical: 115 volts, 1 phase, 13.7 Amps., 60 Hz, 3/4 HP, TEFC motor. Includes 6' electrical cord and plug
Maximum allowable city pressure: 50 PSI
Working temperature: 32-122 degrees Fahrenheit
Maximum working pressure: 140 PSI
Maximum flow rate: 0.5 GPM
Connections: 1" standard NPT
Dimensions: 13.25" high,15.25" long, 7.5" wide.
Weight: 26.7 lbs.
