Pearl by Calpeda Water Boosting System 1/2 HP 115 V FBSMS05-15G30PA (C)

Pearl by Calpeda Pump Flux inline water boosting system 1/2 HP 115/1/60, 20 GPM at 25 PSI, FBSMS05-15G30PA. Ideal for average to large two story homes or long runs of plumbing. Five water outlets can be operated at the same time without substantially reducing performance.

Operation: The Flux control starts the pump as soon as you switch on the tap and continues running until water is not required. The controller continuously monitors the flow of water and will switch it off to avoid damage if the supply becomes inadequate. The systems are compact, quiet and easy to install. Applications Domestic water supply, pressure boosting from city. Type of pump: Centrifugal single stage Pump construction: 304 Stainless steel and corrosion-resistant materials. Maximum operating pressure: Do not exceed 75 PSI Water Pump Protection: Outdoor Use FLUX protection: Water Resistant Tank size: Does not require an additional pressure tank under normal operating conditions. Suction lift: None Maximum inlet pressure: 50 PSI (Must install a pressure reducing valve on the suction side of the pump if the inlet pressure is more than 50 PSI) Electrical: 115 volts, 1 phase, 8.0 Amps, 60 Hz, 1/2 HP, TEFC motor. Includes 8 ft. Power cord. Maximum allowable city pressure: 50 PSI Working temperature: 32-122 degrees Fahrenheit Maximum working pressure: 140 PSI Maximum flow rate: 0.5 GPM Connections: 1" standard NPT Dimensions: 13.25" high,14" long, 7.5" wide. Weight: 19.6 lbs.
